2.4. Optical Elements¶
2.4.1. Spherical Lenses¶
- class raysect.primitive.lens.spherical.BiConvex¶
A bi-convex spherical lens primitive.
A lens consisting of two convex spherical surfaces aligned on a common axis. The two surfaces sit at either end of a cylindrical barrel that is aligned to lie along the z-axis.
The two lens surfaces are referred to as front and back respectively. The back surface is the negative surface most on the z-axis, while the front surface is the positive most surface on the z-axis. The centre of the back surface lies on z=0 and with the lens extending along the +ve z direction.
- Parameters
diameter – The diameter of the lens body.
center_thickness – The thickness of the lens measured along the lens axis.
front_curvature – The radius of curvature of the front surface.
back_curvature – The radius of curvature of the back surface.
parent – Assigns the Node’s parent to the specified scene-graph object.
transform – Sets the affine transform associated with the Node.
material – An object representing the material properties of the primitive.
name – A string defining the node name.
- instance()¶
Returns a new instance of the primitive with the same geometry.
- Parameters
parent (Node) – Assigns the Node’s parent to the specified scene-graph object.
transform (AffineMatrix3D) – Sets the affine transform associated with the Node.
material (Material) – An object representing the material properties of the primitive.
name (str) – A string defining the node name.
- Returns
- class raysect.primitive.lens.spherical.BiConcave¶
A bi-concave spherical lens primitive.
A lens consisting of two concave spherical surfaces aligned on a common axis. The two surfaces sit at either end of a cylindrical barrel that is aligned to lie along the z-axis.
The two lens surfaces are referred to as front and back respectively. The back surface is the negative surface most on the z-axis, while the front surface is the positive most surface on the z-axis. The centre of the back surface lies on z=0 and with the lens extending along the +ve z direction.
- Parameters
diameter – The diameter of the lens body.
center_thickness – The thickness of the lens measured along the lens axis.
front_curvature – The radius of curvature of the front surface.
back_curvature – The radius of curvature of the back surface.
parent – Assigns the Node’s parent to the specified scene-graph object.
transform – Sets the affine transform associated with the Node.
material – An object representing the material properties of the primitive.
name – A string defining the node name.
- instance()¶
Returns a new instance of the primitive with the same geometry.
- Parameters
parent (Node) – Assigns the Node’s parent to the specified scene-graph object.
transform (AffineMatrix3D) – Sets the affine transform associated with the Node.
material (Material) – An object representing the material properties of the primitive.
name (str) – A string defining the node name.
- Returns
- class raysect.primitive.lens.spherical.PlanoConvex¶
A plano-convex spherical lens primitive.
A lens consisting of a convex spherical surface and a plane (flat) surface, aligned on a common axis. The two surfaces sit at either end of a cylindrical barrel that is aligned to lie along the z-axis.
The two lens surfaces are referred to as front and back respectively. The back surface is the plane surface, it is the negative surface most on the z-axis. The front surface is the spherical surface, it is the positive most surface on the z-axis. The back (plane) surface lies on z=0 with the lens extending along the +ve z direction.
- Parameters
diameter – The diameter of the lens body.
center_thickness – The thickness of the lens measured along the lens axis.
curvature – The radius of curvature of the spherical front surface.
parent – Assigns the Node’s parent to the specified scene-graph object.
transform – Sets the affine transform associated with the Node.
material – An object representing the material properties of the primitive.
name – A string defining the node name.
- Returns
- instance()¶
Returns a new instance of the primitive with the same geometry.
- Parameters
parent (Node) – Assigns the Node’s parent to the specified scene-graph object.
transform (AffineMatrix3D) – Sets the affine transform associated with the Node.
material (Material) – An object representing the material properties of the primitive.
name (str) – A string defining the node name.
- Returns
- class raysect.primitive.lens.spherical.PlanoConcave¶
A plano-concave spherical lens primitive.
A lens consisting of a concave spherical surface and a plane (flat) surface, aligned on a common axis. The two surfaces sit at either end of a cylindrical barrel that is aligned to lie along the z-axis.
The two lens surfaces are referred to as front and back respectively. The back surface is the plane surface, it is the negative surface most on the z-axis. The front surface is the spherical surface, it is the positive most surface on the z-axis. The back (plane) surface lies on z=0 with the lens extending along the +ve z direction.
- Parameters
diameter – The diameter of the lens body.
center_thickness – The thickness of the lens measured along the lens axis.
curvature – The radius of curvature of the spherical front surface.
parent – Assigns the Node’s parent to the specified scene-graph object.
transform – Sets the affine transform associated with the Node.
material – An object representing the material properties of the primitive.
name – A string defining the node name.
- Returns
- instance()¶
Returns a new instance of the primitive with the same geometry.
- Parameters
parent (Node) – Assigns the Node’s parent to the specified scene-graph object.
transform (AffineMatrix3D) – Sets the affine transform associated with the Node.
material (Material) – An object representing the material properties of the primitive.
name (str) – A string defining the node name.
- Returns
- class raysect.primitive.lens.spherical.Meniscus¶
A meniscus spherical lens primitive.
A lens consisting of a concave and a convex spherical surface aligned on a common axis. The two surfaces sit at either end of a cylindrical barrel that is aligned to lie along the z-axis.
The two lens surfaces are referred to as front and back respectively. The back surface is concave, it is the negative surface most on the z-axis. The front surface is convex, it is the positive most surface on the z-axis. The centre of the back surface lies on z=0 and with the lens extending along the +ve z direction.
- Parameters
diameter – The diameter of the lens body.
center_thickness – The thickness of the lens measured along the lens axis.
front_curvature – The radius of curvature of the front (convex) surface.
back_curvature – The radius of curvature of the back (concave) surface.
parent – Assigns the Node’s parent to the specified scene-graph object.
transform – Sets the affine transform associated with the Node.
material – An object representing the material properties of the primitive.
name – A string defining the node name.
- instance()¶
Returns a new instance of the primitive with the same geometry.
- Parameters
parent (Node) – Assigns the Node’s parent to the specified scene-graph object.
transform (AffineMatrix3D) – Sets the affine transform associated with the Node.
material (Material) – An object representing the material properties of the primitive.
name (str) – A string defining the node name.
- Returns
